QS18EP6DBQ5 BANNER ⍾ 68758

Optoelektronischer Allzwecksensor der Bauform QS18; WORLD-BEAM QS18 Expert Series: Diffuse Range: 500 mm; Input: 10-30V dc Output: PNP 6 in pigtail Euro-style Pigtail QD Connector; Sensing Beam : Infrared LED; Power : DC; Sensing Mode (General) : Proximity; Housing Style : Rectangular; Primary Housing Material : ABS; Input/Output : Discrete; Power Supply/Supply Voltage : 10-30 V dc; Quick Disconnect Type : M12 (Euro); Operation : Light/Dark Operate; Min Op. Temp. (°C) : -20; Max Op. Temp. (°C) : 70; Output response time (ms) : 0.6; Special Feature: Remote Teach : Yes; Delay at Power-up (ms) : 100; Repeatability (µs) : 75; Number of Pins : 4; NEMA Rating : NEMA 6; IP Rating : IP67; Max Op. Relative Humidity [%] : 95% @ 50°C; Lens Material : PMMA; Adjustments : Teach Button; Barrel Diameter (mm) : N/A; Indicator : LEDs; Feature: Timing (Hold/Delay) : Yes; Feature: Quick Disconnect : Yes

Typ

QS18

Linsenmaterial

PMMA

Sensorstrahl

Infrared LED

Connection

Pigtail QD

Typische Reaktionszeit

100 ms

Stromversorgungstyp

DC

Stromversorgung

10-30 V dc

Indikator

LEDs

Schutzart

IP67
