Q45BW22FP BANNER ⍾ 36844

Lichtleiter-Verstärker: Bauform Q45; Q45 Series: Plastic Fiber Optic Range: depends on fiber; Input: 90-250 V ac Output: SPST Solid-state Relay 2 m (6.5 ft) Cable; Power : AC; Housing Style : Rectangular; Primary Housing Material : Thermoplastic; Input/Output : Discrete; Color LED - Amplifiers : Red; Fiber Type : Plastic and Glass; Output : Solid-State AC Switch; Quick Disconnect Type : No QD; Output Type (Specific) : Single Discrete; Repeatability (µs) : 500; Number of Pins : 3; IP Rating : IP67; NEMA Rating : NEMA 6P; Max Op. Temperature (°C) : 70; Min Op. Temperature (°C) : -40; Max Op. Relative Humidity (%) : 90% @ 50°C; Adjustments : Potentiometer; Delay at Power-up (ms) : 100; Indicator Display Type : Indicator LEDs; Feature: Timing (Hold/Delay) : Yes; Housing Material : Thermoplastic

Typ

Q45

Connection

Cable

Typische Reaktionszeit

100 ms

Stromversorgung

90-250 V ac

Stromversorgungstyp

AC

Schutzart

IP67
