M18SP6D BANNER ⍾ 48662

Sensor der Bauform M18 zur Montage auf 18-mm-Metallgewinderohr; EZ-BEAM M18 Series: Diffuse Range: 100 mm; Input: 10-30V dc Output: Complementary PNP 2 m (6.5 ft) cable; Sensing Beam : Infrared LED; Power : DC; Sensing Mode (General) : Proximity; Housing Style : Barrel; Primary Housing Material : Stainless Steel; Input/Output : Discrete; Power Supply/Supply Voltage : 10-30 V dc; Connection : Cable; Quick Disconnect Type : No QD; Operation : Light/Dark Operate; Min Op. Temp. (°C) : -40; Max Op. Temp. (°C) : 70; Repeatability (µs) : 750; Number of Pins : 4; NEMA Rating : NEMA 6P; IP Rating : IP69; Max Op. Relative Humidity [%] : 90% @ 50°C; Lens Material : Acrylic; Adjustments : N/A; Indicator : LEDs; Feature: Washdown Rated : Yes; Feature: Encapsulated : Yes; Feature: Chemical Resistant : Yes; Feature: Health/ Marginal Signal Output : Yes

Typ

M18

Linsenmaterial

Acrylic

Sensorstrahl

Infrared LED

Connection

Cable

Typische Reaktionszeit

100 ms

Stromversorgungstyp

DC

Stromversorgung

10-30 V dc

Indikator

LEDs

Schutzart

IP69
