M18SN6FF25Q BANNER ⍾ 58432

Sensor der Bauform M18 zur Montage auf 18-mm-Metallgewinderohr; EZ-BEAM M18 Series: Fixed Field Range: 25 mm; Input: 10-30 V dc Complementary NPN Euro M12 4-pin Integral QD; Sensing Beam : Infrared LED; Power : DC; Sensing Mode (General) : Proximity; Sensing Mode (Detailed) : Background Suppression (Fixed); Housing Style : Barrel; Primary Housing Material : Stainless Steel; Input/Output : Discrete; Quick Disconnect Type : M12 (Euro); Operation : Light/Dark Operate; Min Op. Temp. (°C) : -40; Max Op. Temp. (°C) : 70; Delay at Power-up (ms) : 100; Repeatability (µs) : 750; IP Rating : IP69; NEMA Rating : NEMA 6P; Max Op. Relative Humidity [%] : 90% @ 50°C; Lens Material : Acrylic; Adjustments : N/A; Indicator : LEDs; Feature: Washdown Rated : Yes; Feature: Encapsulated : Yes; Feature: Chemical Resistant : Yes; Feature: Quick Disconnect : Yes; Feature: Health/ Marginal Signal Output : Yes

Typ

M18

Linsenmaterial

Acrylic

Sensorstrahl

Infrared LED

Connection

Integral QD

Typische Reaktionszeit

100 ms

Stromversorgungstyp

DC

Stromversorgung

10-30 V dc

Indikator

LEDs

Schutzart

IP69
