SICK WTV2S-2P3285S45

WTV2S-2P3285S45 SICK ⍾ 1094671 ⍾ WTV2S2P3285S45

Features: Sensor/ detection principle: Photoelectric proximity sensor, Background suppression; Dimensions (W x H x D): 7.7 mm x 21.8 mm x 13.5 mm; Housing design (light emission): Rectangular; Sensing range max.: 1 mm ... 36 mm 1); Sensing range: 4 mm ... 30 mm 1); Type of light: Visible blue light; Light source: LED 2); Light spot size (distance): 2 mm (10 mm)3 mm; Wave length: 445 nm; Adjustment: Cable (Teach-in); Special applications: Detecting small objects, Detecting uneven, shiny objects, Detecting objects wrapped in film; Special features: V-opticsPreset 14 mm on black; Mechanics/electronics: Supply voltage: 10 V DC ... 30 V DC 1); Ripple: ≤ 5 Vpp 2); Current consumption: 20 mA 3); Switching output: PNP; Switching mode: Light switching; Output current Imax.: < 50 mA; Response time: < 0.5 ms 4); Switching frequency: 1,000 Hz 5); Connection type: Cable with M8 male connector, 4-pin, 2 m 6); Cable material: PVC; Cable diameter: Ø 3 mm; Circuit protection: A 7)B 8)D 9); Housing material: Plastic, ABS/PC; Optics material: Plastic, PMMA; Enclosure rating: IP67; Ambient operating temperature: –25 °C ... +50 °C; Ambient storage temperature: –40 °C ... +75 °C; Classifications: ECl@ss 5.0: 27270904; ECl@ss 5.1.4: 27270904; ECl@ss 6.0: 27270904; ECl@ss 6.2: 27270904; ECl@ss 7.0: 27270904; ECl@ss 8.0: 27270904; ECl@ss 8.1: 27270904; ECl@ss 9.0: 27270904; ECl@ss 10.0: 27270904; ECl@ss 11.0: 27270904; ETIM 5.0: EC002719; ETIM 6.0: EC002719; ETIM 7.0: EC002719; UNSPSC 16.0901: 39121528
