REI-E-112I8T-2B512-C Turck ⍾ 100012010 ⍾ REIE112I8T2B512C
Incremental Encoder; Flange with mounting element, Ø 40 mm; Blind hole hollow shaft, Ø 8mm; Optical measuring principle; Shaft material: stainless steel; Protection class IP64 on housing and shaft side; ‐20…+70 °C; Max. 4500 rpm; 10…30 VDC; Cable connection, 8-pole; Push-pull, with inverted signals; Pulse frequency max. 300 kHz; 512 pulses per revolution
Related in rei-e-112 / Encoders ⍾ Page 1
-
REI-E-112I8E-2B360-C
Incremental Encoder; Flange with stator coupling, Ø 46 mm; Blind hole hollow shaft, Ø 8 mm (plug-in depth max. 18 mm); Optical measuring principle; Shaft material: stainless steel; …
-
REI-E-112I8E-2B512-C
Incremental Encoder; Flange with stator coupling, Ø 46 mm; Blind hole hollow shaft, Ø 8 mm (plug-in depth max. 18 mm); Optical measuring principle; Shaft material: stainless steel; …
-
REI-E-112I8T-2B360-C
Incremental Encoder; Flange with mounting element, Ø 40 mm; Blind hole hollow shaft, Ø 8mm; Optical measuring principle; Shaft material: stainless steel; Protection class IP64 on h …
-
REI-E-112I8E-2B1024-C
Incremental Encoder; Flange with stator coupling, Ø 46 mm; Blind hole hollow shaft, Ø 8 mm (plug-in depth max. 18 mm); Optical measuring principle; Shaft material: stainless steel; …
-
REI-E-112I8E-2B2500-C
Incremental Encoder; Flange with stator coupling, Ø 46 mm; Blind hole hollow shaft, Ø 8 mm (plug-in depth max. 18 mm); Optical measuring principle; Shaft material: stainless steel; …
-
REI-E-112I8T-2B1024-C
Incremental Encoder; Flange with mounting element, Ø 40 mm; Blind hole hollow shaft, Ø 8mm; Optical measuring principle; Shaft material: stainless steel; Protection class IP64 on h …
-
REI-E-112I8T-2B2500-C
Incremental Encoder; Flange with mounting element, Ø 40 mm; Blind hole hollow shaft, Ø 8mm; Optical measuring principle; Shaft material: stainless steel; Protection class IP64 on h …
-
REI-E-112IA0E-2B360-C
Incremental Encoder; Flange with stator coupling, Ø 46 mm; Blind hole hollow shaft, Ø 6.35 mm (plug-in depth max. 18 mm); Optical measuring principle; Shaft material: stainless ste …
-
REI-E-112IA0E-2B512-C
Incremental Encoder; Flange with stator coupling, Ø 46 mm; Blind hole hollow shaft, Ø 6.35 mm (plug-in depth max. 18 mm); Optical measuring principle; Shaft material: stainless ste …
-
REI-E-112IA0T-2B360-C
Incremental Encoder; Flange with mounting element, Ø 40 mm; Blind hole hollow shaft, Ø 6.35mm; Optical measuring principle; Shaft material: stainless steel; Protection class IP64 o …
-
REI-E-112IA0T-2B512-C
Incremental Encoder; Flange with mounting element, Ø 40 mm; Blind hole hollow shaft, Ø 6.35mm; Optical measuring principle; Shaft material: stainless steel; Protection class IP64 o …
-
REI-E-112IA0E-2B1024-C
Incremental Encoder; Flange with stator coupling, Ø 46 mm; Blind hole hollow shaft, Ø 6.35 mm (plug-in depth max. 18 mm); Optical measuring principle; Shaft material: stainless ste …
