SICK IQ40-40NNOKC0K

IQ40-40NNOKC0K SICK ⍾ 1071856 ⍾ IQ4040NNOKC0K

Features: Housing: Rectangular; Housing: Short-body; Dimensions (W x H x D): 40 mm x 40 mm x 66 mm; Sensing range Sn: 40 mm; Safe sensing range Sa: 32.4 mm; Installation type: Non-flush; Switching frequency: 100 Hz; Connection type: Male connector M12, 4-pin; Switching output: NPN; Output function: NC; Electrical wiring: DC 3-wire; Enclosure rating: IP67, IP68, IP69K; Special applications: Difficult application conditions; Mechanics/electronics: Supply voltage: 10 V DC ... 30 V DC; Ripple: ≤ 10 Vpp 1); Voltage drop: ≤ 2 V; Current consumption: 20 mA 2); Time delay before availability: ≤ 50 ms; Hysteresis: 3 % ... 15 % 3); Reproducibility: ≤ 6 %; Temperature drift (of Sr): ± 10 %; Continuous current Ia: ≤ 200 mA; Short-circuit protection: ✔; Reverse polarity protection: ✔; Power-up pulse protection: ✔; Shock and vibration resistance: 30 g, 11 ms / 10 ... 55 Hz, 1 mm; Ambient operating temperature: –25 °C ... +85 °C; Ambient storage temperature: –40 °C ... +85 °C; Housing material: Plastic, PA 66; Sensing face material: Plastic, PA 66; Tightening torque, max.: 1.8 Nm; Items supplied: Push-lock mounting system (1x); Protection class: II 4); UL File No.: E348498; Safety-related parameters: MTTFD: 1,406 years; DCavg: 0%; Reduction factors: Note: The values are reference values which may vary; Stainless steel (V2A, 304): Approx. 0.8; Aluminum (Al): Approx. 0.34; Copper (Cu): Approx. 0.27; Brass (Br): Approx. 0.38; Installation note: Remark: Associated graphic see "Installation"; A: 42 mm; B: 150 mm; C: 40 mm; D: 120 mm; E: 40 mm; F: 150 mm; Classifications: ECl@ss 5.0: 27270101; ECl@ss 5.1.4: 27270101; ECl@ss 6.0: 27270101; ECl@ss 6.2: 27270101; ECl@ss 7.0: 27270101; ECl@ss 8.0: 27270101; ECl@ss 8.1: 27270101; ECl@ss 9.0: 27270101; ECl@ss 10.0: 27270101; ECl@ss 11.0: 27270101; ETIM 5.0: EC002714; ETIM 6.0: EC002714; ETIM 7.0: EC002714; UNSPSC 16.0901: 39122230
