ifm IB5133

IB5133 ifm ⍾ IBE3030-FPKG

Inductive sensor; Operating voltage [V] : 10...36 DC; Protection class : II; Reverse polarity protection : yes; Electrical design : PNP; Output function : normally open / normally closed; (selectable); Max. voltage drop switching output DC [V] : 2.5; Permanent current rating of switching output DC [mA] : 200; Switching frequency DC [Hz] : 350; Short-circuit protection : yes; Type of short-circuit protection : pulsed; Overload protection : yes; Sensing range [mm] : 30; Real sensing range Sr [mm] : 30 ± 10 %; Operating distance [mm] : 0...24.3; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.4 / copper: 0.3; Switch point drift [% of Sr] : -10...10; Ambient temperature [°C] : -25...80; Housing : cylindrical; Mounting : non-flush mountable; Materials : PBT; end cap: PC; Items supplied : Mounting clamps: 1

Connection
terminals: ...2.5 mm²; Cable sheath: Ø 7...13 mm; Cable gland: M20 X 1.5
No. of inputs/outputs
Number of analogue outputs: 1
Current consumption
15; (24 V) mA
Voltage supply
24 V
Display
switching status: 1 x LED, yellow
Degree of protection
IP 65
Weight
187 g
Dimensions
Ø 34 / L = 98 mm
