IA5063 ifm ⍾ IAE3010-APKG

Inductive sensor; Operating voltage [V] : 10...36 DC; Protection class : II; Reverse polarity protection : yes; Electrical design : PNP; Output function : normally closed; Max. voltage drop switching output DC [V] : 2.5; Permanent current rating of switching output DC [mA] : 250; Switching frequency DC [Hz] : 300; Short-circuit protection : yes; Type of short-circuit protection : pulsed; Overload protection : yes; Sensing range [mm] : 10; Real sensing range Sr [mm] : 10 ± 10 %; Operating distance [mm] : 0...8.1; Correction factor : steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.3 / copper: 0.2; Hysteresis [% of Sr] : 1...15; Switch point drift [% of Sr] : -10...10; Ambient temperature [°C] : -25...80; Housing : cylindrical; Mounting : non-flush mountable; Materials : PBT; LED window: PC; Items supplied : Mounting clamps: 1

Connection: terminals: ...2.5 mm²; Cable sheath: Ø 4.5...10 mm; Cable gland: M16 X 1.5
No. of inputs/outputs: Number of analogue outputs: 1
Current consumption: 15; (24 V) mA
Voltage supply: 24 V
Display: switching status: 1 x LED, yellow
Degree of protection: IP 65
Weight: 84 g
Dimensions: Ø 20 / L = 92 mm
